IP-COM Switch 5port Gigabit G1105PD w/4port PoE

Технички спецификации

G1105PD 5-Port Gigabit PD Switch With 4-Port PoE G2224D is a 24-port Gigabit intelligent cloud management switch independently designed by IP-COM. It supports cloud WEB platform management and Profi APP management. It can automatically detect loops and private routers and send alarms. Network maintenance is more efficient, after-sales costs are lower, and switches can be configured without leaving home. • Five 10/100/1000 Mbps auto-negotiation ports • Port 5 supports power supply by a PSE compliant with IEEE 802.3af/at • Ports 1 - 4 support power supply to low-power PDs compliant with IEEE 802.3af • The switch supports auto MDI/MDIX, simplifing the network structure and maintenance • The non-blocking wire-speed forwarding function guarantees the smooth operation of network applications • Full-duplex flow control and half-duplex back pressure control prevent frame loss caused by port blocking • The switch supports the store-and-forward transfer mode and a 2 K MAC address table • The switch supports 9K jumbo frame, improving the forwarding rate of large files • The switch supports IP camera connection and guarantees the smoothness and clearness of monitoring videos Specification Hardware specifications

Network standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at

Transmission media

10Base-T: CAT3 UTP or better; 100Base-TX: CAT5 UTP or better; 1000Base-T: CAT5e UTP or better

Dimensions

100 mm x 100 mm x 26 mm(L x W x H)

Fanless LED indicators

1 x Power LED indicator; 4 x PoE LED indicator; 5 x Link/Act LED indicator Service port description

Fixed ports

5 x 10/100/1000 Mbps auto-negotiation RJ45 ports (supporting Auto MDI/MDIX)

PoE out

PoE standard:IEEE 802.3af; PoE power cable core:8 cores: voltage of cores 1, 2, 4, 5 is +, and cores 3, 6, 7, 8 is -; PoE port:1 - 4; Maximum output power of a single port:15.4 W; Maximum output power of the switch:22 W

PoE in

PoE in standard:IEEE802.3af, IEEE802.3at; PoE in port:5; PoE input:50 - 57V DC, 0.6A

Port lightning protection

6 kV;

Power lightning protection

No; Electrostatic protection:; -

Air discharge

±8 kV; -

Contact discharge

±6 kV

Store-and-forward Switching capacity

10 Gbps

Packet forwarding rate

10

Mbps

14880 pps; 100

Mbps

148800 pps; 1000

Mbps

1488000 pps

Buffer

1 Mb

MAC address table

2 K

Jumbo frame

9 K

Desktop mounting

Support;

Wall mounting

Not support;

Operating temperature

0°C - 45°C;

Storage temperature

-40°C - 70°C;

Operating humidity

(10% - 90%), non-condensing;

Storage humidity

(5% - 90%), non-condensing

Certificates

CQC, FCC, CE, RoHS

Software specifications Protocol

CDMA/CD

MAC address learning

Auto-learning, auto-updating

Function

No https://www.ip-com.com.cn/en/product/G1105PD.html
