UPS Energenie 650VA 390W, 2xSchuko AVR LED RJ45

Технички спецификации

Uninterruptable 650 VA power supply with modified sine wave output Automatic AC voltage regulation (AVR) Intelligent surge-, overload- and short-circuit protection Audible and visual alarms LCD status display Intelligent battery management with overcharge and over-discharge protection

Specifications Type

line interactive

Waveform

sine wave (AC mains), modified (square) sine wave (battery)

Input

220 V AC ± 25%, 50 / 60 Hz ± 10%

Output

220 V AC ± 10%, 50 / 60 Hz ± 1% (220 V AC ± 5 % at inverter mode) Switching timeabout or less than 8 ms

Backup time

8…20 mins (depends on the load)

Battery

sealed lead-acid 12 V DC / 7Ah

Charge time

up to 12 hours

Output sockets

2 pcs x C13, 1 pc x german

Shuko Operating conditions

0°C ~ 40°C, at humidity 20 ~ 90 %RH non condensing

Power

650 VA (390 W)

Charging current

up to 1.2 A

Noise

< 45 dB at 1 m distance

Dimensions

340 x 95 x 165 mm

Product weight

5.2 kg "Cold-start" function System requirements In order to work correclty, the connected load should be at least 5% of the maximum capacity of the UPS. For example, a 700 W UPS needs at least a connected load of 35 W to work.
